Short Clamp Weld Ferrule, 316L SS

(0)No Reviews yet

$18.03 to $176.57

Quantity	Price

SKU: TEG2CS6L

Low stock, order now!

Current Stock: 4

Quantity

Short Clamp Weld Ferrule made from 316L Stainless Steel.

This VNE MaxPure ASME BPE Compliant Bio-Pharm Fitting is available with the following finishes:

20Ra Mechanically Polished Inside Surface with a 32Ra Mechanically Polished Outside Surface, SFF1 (PL)

15Ra Mechanically Polished & Electropolished Inside Surface with a 32Ra Mechanically Polished Outside Surface, SFF4 (PM)

Ordering Code	Nominal Size(in.)	Type	A (in.)	A (mm)	D (in.)	D (mm)

TEG2CS6L.25-..	1/4	A	0.500in.	12.7mm	0.984in.	24.9mm
TEG2CS6L.375-..	3/8	A	0.500in.	12.7mm	0.984in.	24.9mm
TEG2CS6L.5-..	1/2	A	0.500in.	12.7mm	0.984in.	24.9mm
TEG2CS6L.75-..	3/4	A	0.500in.	12.7mm	0.984in.	24.9mm
TEG2CS6L1.0-A..	1	A	0.500in.	12.7mm	1.339in.	34.0mm
TEG2CS6L1.0-..	1	B	0.500in.	12.7mm	1.984in.	50.3mm
TEG2CS6L1.5-..	1 1/2	B	0.500in.	12.7mm	1.984in.	50.3mm
TEG2CS6L2.0-..	2	B	0.500in.	12.7mm	2.516in.	63.9mm
TEG2CS6L2.5-..	2 1/2	B	0.500in.	12.7mm	3.047in.	77.3mm
TEG2CS6L3.0-..	3	B	0.500in.	12.7mm	3.579in.	90.9mm
TEG2CS6L4.0-..	4	B	0.625in.	15.9mm	4.682in.	118.9mm
TEG2CS6L6.0-..	6	B	0.750in.	19.1mm	6.570in.	166.8mm
