Dixon™ 2-way ball valves are quarter-turn, straight through valves that use a ball to shut-off flow by sealing around matching seats to create a uniform sealing. Ball valves are used in situations where a tight shut-off is necessary.

A wide selection of Ball Valves is offered in varied applications. These valves are simple, rugged, and above all, dependable. Pneumatic and electric actuators are available for automated control. All Dixon™ ball valves are assembled without silicones.

Application

Get control with Dixon™ 2 piece industrial brass ball valves. The 2 piece full port valves are used in industrial and commercial applications for a wide range of fluids. The superior low torque-low profile design results in economical operation and exceptional performance.

Working Principal

The 2 piece industrial brass ball valves are operated manually or remotely by a pneumatic or electric actuator. Dixon™ pneumatic actuators are available in spring return or double acting. Electric actuators are available in a variety of voltages and options.

Features and Benefits

• Full port stainless steel ball valve with FNPT ends
• Direct mounting ISO 5211 pad for low profile economical actuation
• Blow-out proof stem
• Low torque design
• RTFE® seats and TFE seals
• Spring loaded stem packing with Belleville washers
• Pressure rating: 1000 PSI WOG
• Temperature range: -40°F to 450°F
