Weld Cross Tee made from 316L Stainless Steel.

This VNE MaxPure ASME BPE Compliant Bio-Pharm Fitting is available with the following finishes:

20Ra Mechanically Polished Inside Surface with a Mill Finished Outside Surface, SFF1 (PC)

20Ra Mechanically Polished Inside Surface with a 32Ra Mechanically Polished Outside Surface, SFF1 (PL)

15Ra Mechanically Polished & Electropolished Inside Surface with a Mill Finished Outside Surface, SFF4 (PD)

15Ra Mechanically Polished & Electropolished Inside Surface with a 32Ra Mechanically Polished Outside Surface, SFF4 (PM)

Ordering Code	Nominal Size(in.)	A (in.)	A (mm)	B (in.)	B (mm)

TE9WWWW6L.25-..	1/4	1.750in.	44.5mm	3.500in.	89.0mm
TE9WWWW6L.375-..	3/8	1.750in.	44.5mm	3.500in.	89.0mm
TE9WWWW6L.5-..	1/2	1.875in.	47.6mm	3.750in.	95.2mm
TE9WWWW6L.75-..	3/4	2.000in.	50.8mm	4.000in.	101.6mm
TE9WWWW6L1.0-..	1	2.125in.	54mm	4.250in.	108.0mm
TE9WWWW6L1.5-..	1 1/2	2.375in.	60.3mm	4.750in.	120.6mm
TE9WWWW6L2.0-..	2	2.875in.	73mm	5.750in.	146.0mm
TE9WWWW6L2.5-..	2 1/2	3.125in.	79.4mm	6.250in.	158.8mm
TE9WWWW6L3.0-..	3	3.375in.	85.7mm	6.750in.	171.4mm
TE9WWWW6L4.0-..	4	4.125in.	104.8mm	8.250in.	209.6mm
TE9WWWW6L6.0-..	6	5.625in.	142.9mm	11.250in.	285.8mm
